2016 Porsche Boxster GTS (981) Technical Specifications
| type | Series Production Car |
| built at | Stuttgart, Germany |
| engine | Flat-6 |
| position | Mid, Longitudinal |
| aspiration | Natural |
| block material | Aluminum |
| valvetrain | DOHC, 4 Valves per Cyl w/VVT & VarioCam Plus |
| fuel feed | Direct Fuel Injection |
| displacement | 3436 cc / 209.68 in³ |
| bore | 97 mm / 3.8 in |
| stroke | 77.5 mm / 3.1 in |
| compression | 12.5:1 |
| power | 246.1 kw / 330 bhp |
| specific output | 96.04 bhp per litre |
| bhp/weight | 250.0 bhp per tonne |
| redline | 7800 |
| body / frame |
Unitary Steel & Aluminum Monocoque w/Aluminum Hood
|
| driven wheels | RWD |
| wheel type | 20-inch Carrera S-wheels |
| front tires | 235/35-20 |
| rear tires | 265/35-20 |
| front brakes |
Ventilated Discs w/4-Piston Aluminum Monobloc Calipers
|
| f brake size | 28 x 330 mm / 1.1 x 13.0 in |
| rear brakes |
Ventilated Discs w/4-Piston Aluminum Monobloc Calipers
|
| r brake size | 20 x 299 mm / 0.8 x 11.8 in |
| f suspension |
MacPherson Struts w/Gas-Pressure Dampers, Anti-Roll Bar
|
| r suspension |
Transverse Control Arms w/Coil Springs over Gas-Pressure Dampers, Anti-Roll Bar
|
| curb weight | 1320 kg / 2911 lbs |
| wheelbase | 2475 mm / 97.4 in |
| front track | 1526 mm / 60.1 in |
| rear track | 1540 mm / 60.6 in |
| length | 4374 mm / 172.2 in |
| width | 1801 mm / 70.9 in |
| height | 1281 mm / 50.4 in |
| transmission | 6-Speed Manual or 7-Speed PDK Automatic |
| tran clutch | 240mm |
| gear ratios | 3.31:1, 1.95:1, 1.41:1, 1.13:1, 0.95:1, 0.81:1 |
| final drive | 3.89:1 |
| top speed | ~281 kph / 174.50 mph |
| 0 – 100 kph | ~4.7 seconds |
