Porsche 962 Specifications
| type | Racing Car |
| built at | Germany |
| engine | Air Cooled, Boxer-6 |
| position | Mid, Longitudinal |
| aspiration | Twin KKK Turbos |
| valvetrain | DOHC, 4 Valves per Cyl |
| fuel feed | Fully-Electronic Bosch Fuel Injection |
| body / frame |
Fiberglass Body over Aluminum Monocoque
|
| driven wheels | RWD |
| front brakes | Discs w/Twin Calipers |
| rear brakes | Discs w/Twin Calipers |
| f suspension | Wishbones w/Coil-Overs |
| r suspension | Rocker Arms w/Coil-Overs |
| curb weight | 820 kg / 1808 lbs |
| wheelbase | 2650 mm / 104.3 in |
| length | 4800 mm / 189.0 in |
| width | 2000 mm / 78.7 in |
| transmission | 5-Speed Gearbox |
Porsche 962 Engines
Type 935/76 (1982)
| Displacement | 2.65 litre (2649 cc) |
| Horsepower | 620 bhp @ 8200 rpm; 1.2 bar boost (standard boost) |
| Torque | 630 Nm |
| Turbochargers | Twin turbo KKK K26 |
| Cooling | Water-cooled cylinder heads, air-cooled cylinders with fan |
| Fuel feed | Kugelfischer mechanical injection |
Type 935/79 (1983 – 1986)
| Displacement | 2.65-litre (subsequently 2869 cc, 2994 cc and 3164 cc) |
| Horsepower | 620 bhp @ 8200 rpm; 1.2 bar boost (2.649-litre) |
| Torque | 630 Nm |
| Turbochargers | Twin turbo KKK K26 |
| Cooling | Water-cooled cylinder heads, air-cooled cylinders with fan |
| ECU | Bosch 1.2 Motronic engine management |
Type 962/70 (1984)
| Displacement | 2.8-litre (2869 cc) |
| Horsepower | 680 bhp @ 8200 rpm |
| Torque | 660 Nm |
| Turbocharger | Single turbo KKK K36 |
| Cooling | Air-cooled cylinder heads and cylinders with fan |
| ECU | Bosch Motronic 1.2 engine management |
Type 962/71 (1985-1987) IMSA engine
| Displacement | 3.2-litre (3164 cc) |
| Horsepower | 720 bhp @ 7300 rpm |
| Torque | 720 Nm |
| Turbocharger | Single Turbo – KKK K36 or Garrett ANDIAL |
| Cooling | Air-cooled cylinder heads and cylinders with fan |
| ECU | Bosch Motronic 1.2 management |
Type 935/82 (1987)
| Displacement | 3.0-litre (2994 cc) |
| Horsepower | 740 bhp (standard boost) |
| Torque | 710 Nm |
| Turbochargers | Twin Turbo KKK K26 |
| Cooling | Water-cooled cylinder heads with air-cooled cylinders |
| ECU | Bosch Motronic 1.7 engine management |
Type 935/83 (1988-1990)
| Displacement | 3.0-litre (2994 cc) [Restrictors] |
| Horsepower | 740 bhp |
| Torque | 710 Nm |
| Turbocharger | Twin Turbo KKK K26 or ANDIAL Garrett |
| Cooling | Water-cooled cylinder heads and cylinders |
| ECU | Bosch Motronic 1.7 engine management |
Type 962/72 (1987-1992)
| Displacement | 3.0-litre (2994 cc) [Restrictors] |
| Horsepower | 695 bhp @ 8200 rpm |
| Torque | 710 Nm |
| Turbocharger | Single Turbo – KKK K32 or Garrett |
| Cooling | Air-cooled cylinder heads and cylinders with fan |
| ECU | Bosch Motronic 1.2 management |
Type 935/86 (1989-1994)
| Displacement | 3.2-litre (3164 cc) [Restrictors] |
| Horsepower | 740 bhp @ 8200 rpm |
| Torque | 715 Nm |
| Turbocharger | Twin Turbo – KKK K26 or ANDIAL Garrett with electronically controlled waste gates |
| Cooling | Water-cooled cylinder heads and cylinders |
| ECU | Bosch 1.7 Motronic engine management |
