Porsche 935/76 Specifications
| type | Racing Car |
| built at | Germany |
| engineers | Norbert Singer |
| production | 2 units |
| engine | Type 930/72 Boxer-6 |
| position | Rear, Longitudinal |
| aspiration | KKK Turbocharger |
| block material | Aluminum |
| valvetrain | SOHC, 2 Valves perCyl |
| fuel feed | Bosch Mechanical Fuel Injection |
| displacement | 2856 cc / 174.28 in³ |
| bore | 92.8 mm / 3.7 in |
| stroke | 70.4 mm / 2.8 in |
| compression | 6.5:1 |
| power | 417.6 kw / 560 bhp @ 8000 rpm |
| specific output | 196.08 bhp per litre |
| bhp/weight | 622.22 bhp per tonne |
| torque | 587.1 nm / 433 ft lbs @ 5400 rpm |
| body / frame | Unitary Steel Monocoque w/Fiberglas Panels |
| driven wheels | RWD |
| front brakes | Ventilated Discs w/4-Piston Calipers |
| rear brakes | Ventilated Discs w/4-Piston Calipers |
| front wheels | F 40.6 x 26.7 cm / 16 x 10.5 in |
| rear wheels | R 48.3 x 38.1 cm / 19 x 15 in |
| steering | Rack & Pinion |
| f suspension |
MacPherson Struts w/Bilstein Dampers, Adjustable Anti-Roll Bar
|
| r suspension |
Double Wishbones w/Bilstein Dampers, Adjustable Anti-Roll Bar
|
| curb weight | 900 kg / 1985 lbs |
| weight distro | 40 % / 60 % |
| wheelbase | 2271 mm / 89.4 in |
| front track | 1501 mm / 59.1 in |
| rear track | 1557 mm / 61.3 in |
| length | 4681 mm / 184.3 in |
| width | 1971 mm / 77.6 in |
| transmission | 4-Speed Manual |
| top speed | ~339.50 kph / 211 mph |
| 0 – 60 mph | ~3.3 seconds |
| 0 – 100 mph | ~6.1 seconds |
| 0 – 1/4 mile | ~8.9 seconds |
| fuel econ epa | 52 L/100 km or 4.52 mpg-us |
| city fuel econ epa | 58.80 L/100 km or 4 mpg-us |
| key drivers |
Jacky Ickx, Jochen Mass, Rolf Stommelen, Manfred Schurti
|
| race victories | 1976 Watkins Glen 6 Hours, 1976 Dijon 6 Hours |
