Porsche 934/5 Specifications
| Engine | Flat-six engine |
| Position | Rear, Longitudinal |
| Aspiration | KKK Turbocharger |
| Valvetrain | SOHC |
| Fuel Feed | K-Jetronic Mechanical Injection |
| Displacement | 2993cc / 182.64 in³ |
| Compression | 10.3:1 |
| Power | 485 bhp @ 7000 rpm |
| Specific Output | 162.04 bhp per litre |
| Torque | 434 ft lbs @ 5400 rpm |
| Redline | 8500 rpm |
| Body/Frame | Unit Steel with some fiberglass |
| Driven Wheels | Rear Engine / RWD |
| Wheel Type | BBS Center-Lock |
| Front Brakes | F 40.6 x 26.7 cm / 16 x 10.5 in |
| Rear Brakes | R 40.6 x 31.8 cm / 16 x 12.5 in |
| Steering | Rack and pinion |
| Wheel Base | 2271 mm / 89.4 in |
| Front Track | 1402 mm / 55.2 in |
| Rear Track | 1422 mm / 56.0 in |
| Length | 4128 mm / 162.5 in |
| Width | 1651 mm / 65.0 in |
| Height | 1321 mm / 52.0 in |
| Transmission | 5-Speed Manual |
| Tran Clutch | Single Plate |
| Gear Ratios |
3.18:1, 1.83:1, 1.26:1, 0.925:1, 0.724:1
|
| Final Drive | 4.43:1 |
| Top Speed | ~286.5 km/h / 178.0 mph |
| 0 – 60 mph | ~5.6 seconds |
| 0 – 100 mph | ~12.0 seconds |
| 0 – 1/4 mile | ~13.2 seconds |
| Fuel Capacity | 120 litres or 31.68 gal. |
