| Engine |
|
| Engine layout |
Rear Engine |
| Engine type |
Boxer, twin-turbo |
| Cylinders |
6 |
| Valves per cylinder |
4 |
| Construction |
Aluminum crankcase and heads |
| Fuel injection |
Direct Fuel Injection (DFI) |
| Fuel |
Premium |
| Displacement (Liters) |
3.8 L |
| Bore/Stroke (mm/mm) |
102 mm / 77.5 mm |
| Maximum power output @ engine speed |
540 hp @ 6400 rpm |
| Maximum torque with Overboost @ engine speed |
524 lb.-ft. @ 2250-4000 rpm |
| Maximum torque @ engine speed |
486 lb.-ft. @ 1950-5000 rpm |
| Maximum engine speed |
7000 |
| Compression ratio |
9.8:1 |
| Output per liter |
142.1 hp |
| Lubrication |
Integrated dry-sump |
| Electrical System |
12 V, 2100 W alternator; battery capacity 95 Ah |
| Power to weight ratio (lb/hp) |
6.8 |
| Drivetrain |
Active all wheel drive |
| Chassis & Suspension |
|
| Body |
Monocoque lightweight body in a combination of steel, aluminum and magnesium |
| Front Axle |
MacPherson strut with anti-roll bar |
| Rear Axle |
Aluminum multi-link with anti-roll bar |
| Steering System |
Variable ratio electromec. power steering |
| Steering Ratio |
15.0:1 (on-center) to 12.5:1 |
| Turning Circle |
34.8 ft |
| Transmission |
7 |
| Number of gears Transmission type |
7-speed PDK |
| Ratios |
|
| 1st |
3.91 |
| 2nd |
2.29 |
| 3rd |
1.58 |
| 4th |
1.18 |
| 5th |
0.94 |
| 6th |
0.79 |
| 7th |
0.62 |
| Reverse |
3.55 |
| Front Axle Ratio |
3.4 |
| Rear Axle Ratio |
3.3 |
| Final Drive Ratio |
TBD |
| Clutch/Converter diameter (inches) |
8.7 / 6.4 inches |
| Dimensions, Aerodynamics, & Weight |
|
| Length (inches/mm) |
177.4 in. / 4507 mm |
| Wheelbase (inches/mm) |
96.5 in. / 2450 mm |
| Width w/ mirrors (inches/mm) |
77.9 in. / 1978 mm |
| Width w/o mirrors (inches/mm) |
74.0 in. / 1880 mm |
| Height |
50.9 in. / 1294 mm |
| Track width front (inches/mm) |
60.7 in. / 1541 mm |
| Track width rear (inches/mm) |
62.6 in. / 1590 mm |
| Drag coefficient (Cd) |
0.32 |
| Cargo area volume (cu.-ft.) front trunk |
115 l / 4.06 cu.-ft. |
| Cargo area volume (cu.-ft.) rear seats |
260 l / 9.18 cu.-ft. |
| Fuel tank capacity refill volume (gal) |
17.9 gal. |
| Curb weight (lbs) |
3671 lbs. |
| Gross Vehicle Weight (lbs) |
4553 lbs. |
| Payload range (lbs) depend on options |
882 lbs. |
| Performance |
|
| Top track speed (mph) |
198 mph |
| Acceleration 0-60 (sec) |
3.0 sec. |
| Quarter mile time |
11.2 sec. |
| Fuel Economy/Rating |
|
| City |
19 mpg |
| Highway |
24 mpg |
| Combined |
21 mpg |
