| Engine layout |
Rear engine |
| Engine type |
6-cylinder boxer engine |
| Cylinders |
6 |
| Valves per cylinder |
4 |
| Construction |
Aluminum block and heads |
| Fuel injection |
Direct Fuel Injection (DFI), 140 bar |
| Fuel |
Premium |
| Displacement |
3.8 liter |
| Bore/Stroke |
102.0 mm / 177.5 mm |
| Maxmimum power output @ engine speed |
395 bhp @ 7400 rpm |
| Maximum torque @ engine speed |
325 lb.-ft. @ 5,600 rpm |
| Electrical System |
12 volt, 2100 watt alternator, 70 Ah battery |
| Maximum engine speed |
7,800 rpm |
| Compression ratio |
12.5:1 |
| Power to weight ratio (lbs/hp) (PDK) |
8.57 (8.68) |
| Output per liter |
105.3 hp/l |
| Lubrication |
Integrated dry-sump |
| Engine Management |
EMS SDI 9.1 |
| Drivetrain Chassis & Suspension |
All-wheel-drive, with electronically controlled, hydraulically actuated multi-plate center differential, locking rear differential, PTM |
| Body |
2+2-seat, cabriolet aluminum and steel composite unibody, aluminum doors and hood |
| Front Axle |
Independent MacPherson strut with tranverse and longitudinal control arm, shock inside spring |
| Rear Axle |
Independent multi-link suspension with shock inside spring |
| Steering System |
Electro-mechanical power steering |
| Steering Ratio |
12.25:1 – 16.6:1 |
| Turning Circle |
36.4 ft. |
| Brakes & Wheels |
|
| Caliper type |
Fixed aluminum monobloc |
| Rotor material |
Steel, drilled and internally vented |
| Caliper color |
Red |
| Number of pistons (front/rear) |
6/4 |
| Steel Rotor diameter (front/rear) mm |
340/330 |
| Steel Rotor thickness (front/rear) mm |
34/28 |
| PCCB rotor diameter (front/rear)mm |
350/350 (Opt.) |
| PCCB rotor thickness(front/rear)mm |
34/28 (Opt.) |
| Wheel type (standard) |
Carrera S Wheel |
| Wheels and tires front (standard) |
8.5J x 20 245/35 ZR 20 |
| Wheels and tires rear (standard) |
11J 20 305/30 ZR 20 |
| Transmission |
|
| Manual Transmission PDK Transmission (Opt.) |
7-speed manual 7-speed PDK |
| Ratios (PDK in parentheses) |
|
| 1st |
3.91 (3.91) |
| 2nd |
2.29 (2.29) |
| 3rd |
1.55 (1.65) |
| 4th |
1.30 (1.30) |
| 5th |
1.08 (1.08) |
| 6th |
0.88 (0.88) |
| 7th |
0.71 (0.62) |
| Reverse |
3.55 (3.55) |
| Final Drive Ratio |
3.44:1 (3.44:1) |
| Dimensions,Aerodynamics, & Weight |
|
| Length (inches) |
176.8 |
| Wheelbase (inches) |
96.4 |
| Width w/ mirrors (inches) |
77.8 |
| Width w/o mirrors (inches) |
72.9 |
| Height (inches) (PDK) |
50.8 (50.7) |
| Track width front (inches) |
60.3 |
| Track width rear (inches) |
61.4 |
| Drag coefficient (Cd) |
0.3 |
| Legroom* (inches) |
TBD |
| Headroom (inches) |
TBD |
| Cargo area volume (cu.-ft.) seats down |
10 |
| Fuel tank capacity refill volume (gal) |
17.9 gal. |
| Curb weight (lbs) (PDK) |
3,428 lbs (3,472 lbs) |
| Gross Vehicle Weight (lbs) (PDK) |
4,321 lbs (4,365 lbs) |
| Performance |
|
| Top track speed (mph) |
183 mph |
| Top track speed (mph) (PDK) |
182 mph |
| Acceleration 0-60 (mph) |
4.6 seconds |
| Acceleration 0-60 (mph) (PDK) |
4.4 seconds (4.2 seconds w/ Sport Chrono) |
| 1/4 mile from standing start (secs) |
12.9 seconds |
| 1/4 mile from standing start (secs) (PDK) |
12.8 seconds (12.5 seconds w/ Sport Chrono) |
