| Engine |
|
| Engine layout |
Rear Engine |
| Engine type |
Boxer, twin-turbo |
| Cylinders |
6 |
| Valves per cylinder |
4 |
| Construction |
Aluminum crankcase and heads |
| Fuel injection |
Direct Fuel Injection (DFI) |
| Fuel |
Premium |
| Displacement (Liters) |
3.0 L |
| Bore/Stroke (mm/mm) |
91.0 mm / 76.0 mm |
| Maximum power output @ engine speed |
370 hp @ 6500 |
| Maximum torque @ engine speed |
331 lb.-ft. @ 1700-5000 |
| Maximum engine speed |
7500 |
| Compression ratio |
10.0 1 |
| Output per liter |
124.1 hp |
| Lubrication |
Integrated dry-sump |
| Electrical System |
12 V, 2450 W alternator; battery capacity 80 Ah |
| Power to weight ratio (lb/hp) Drivetrain |
9.4 (manual) /9.5 (PDK) Active all-wheel drive |
| Chassis & Suspension |
|
| Body |
Monocoque lightweight body in a combination of steel, aluminum, and magnesium |
| Front Axle |
MacPherson strut with anti-roll bar |
| Rear Axle |
Aluminum multi-link with anti-roll bar |
| Steering System |
Variable ratio electromec. power steering |
| Steering Ratio |
16.6:1 (on-center) to 12.5:1 |
| Steering Ratio with rear-axle steering |
not available |
| Turning Circle |
36.7 ft |
| Brakes & Wheels |
|
| Caliper type |
Aluminum monobloc fixed-caliper brake |
| Rotor material |
Steel |
| Caliper color |
Black |
| Number of pistons (front/rear) |
4 / 4 |
| Rotor diameter (front/rear) mm |
330 mm / 330 mm |
| Rotor thickness (front/rear) mm |
34 mm / 28 mm |
| Standard wheels |
19″ Carrera |
| Wheels (front/rear |
8.5J x 19″ / 11.5J x 19″ |
| Tires (front/rear) |
235/40 ZR 19 / 295/35 ZR 19 |
| Transmission |
|
| Number of gears |
7 |
| Transmission type |
7-speed manual / 7-speed PDK |
| Ratios |
|
| 1st |
3.91 / 3.91 |
| 2nd |
2.29 / 2.29 |
| 3rd |
1.58 / 1.58 |
| 4th |
1.18 / 1.18 |
| 5th |
0.94 / 0.94 |
| 6th |
0.79 / 0.79 |
| 7th |
0.62 / 0.62 |
| Reverse |
3.55 / 3.55 |
| Final drive ratio front axle |
3.46 / 3.46 |
| Total Rear Axle Ratio |
3.09 / 3.09 |
| Clutch/Converter diameter (inches) |
9.0 inches (man.) / 8.0/6.0 inches (PDK) |
| Dimensions, Aerodynamics, & Weight |
|
| Length (inches/mm) |
177.1 in. / 4499 mm |
| Wheelbase (inches/mm) |
96.5 in. / 2450 mm |
| Width w/ mirrors (inches/mm) |
77.9 in. / 1978 mm |
| Width w/o mirrors (inches/mm) |
72.9 in. / 1852 mm |
| Height |
50.7 in. / 1288 mm |
| Track width front (inches/mm) |
60.7 in. / 1541 mm |
| Track width rear (inches/mm) |
61.3 in. / 1558 mm |
| Drag coefficient (Cd) |
0.3 |
| Legroom (inches) |
TBD |
| Headroom (inches) |
TBD |
| Cargo area volume (cu.-ft.) front trunk |
125 l / 4.41 cu.-ft. |
| Cargo area volume (cu.-ft.) rear seats |
160 l / 5.65 cu.-ft. |
| Fuel tank capacity – refill volume (gal) |
17.9 gal. |
| Curb weight (lbs) |
3461 lbs. (man.) / 3505 lbs. (PDK) |
| Gross Vehicle Weight (lbs) |
4133 lbs. (man.) / 4166 lbs. (PDK) |
| Payload range (lbs) |
672 lbs. (man.) / 661 lbs. (PDK) |
| Performance |
|
| Top track speed manual (mph) |
179 mph |
| Top track speed PDK (mph) |
178 mph |
| Acceleration 0-60 manual (sec) |
4.5 sec. |
| Acceleration 0-60 PDK (sec) |
4.3 sec. |
| Acceleration 0-60 PDK with Launch Control (sec) |
4.1 sec. |
| Quarter mile time manual (sec) |
12.9 sec. |
| Quarter mile time PDK (sec) |
12.7 sec. |
| Quarter mile time PDK with Launch Control (sec) |
12.6 sec. |
| Fuel Economy/Rating |
– |
| City |
19 mpg (manual) / 22 mpg (PDK) |
| Highway |
28 mpg (manual) / 28 mpg (PDK) |
| Combined |
22 mpg (manual) / 24 mpg (PDK) |
