1968 – 1969 Porsche 911 T Targa 2.0 (SWB & LWB) Technical Specifications
| Engine Type | Flat 6 |
| Induction |
Normally-aspirated
|
| Cooling | Air/oil-cooled |
| Valvetrain |
Single overhead camshaft
|
| Injection | Carburetor |
| Bore X Stroke |
3.15 in/80 mm x 2.60 in/66 mm
|
| Displacement |
121.45 cu-in/1,991 cc
|
| Horsepower |
110 bhp @ 5800 rpm
|
| Torque |
116 lb-ft @ 4200 rpm
|
| Max Rpm | 6500 |
| Compression Ratio | 8.6:1 |
| Transmission Options |
4-speed manual, 5-speed manual, 4-speed Sportomatic
|
| Chassis Type |
Rear-engined, rear-wheel drive
|
| Body / Frame | Unitary Steel |
| Curb Weight | 2,249 lbs. |
| Height |
51.97 in/1,320 mm
|
| Ground Clearance | 5.91 in/150 mm |
| Length |
163.90 in/4,163 mm
|
| Wheelbase |
89.29 in/2,268 mm
|
| Width |
63.39 in/1,610 mm
|
| Track Front |
53.62 in/1,362 mm
|
| Track Rear |
52.87 in/1,343 mm
|
| Drag Coefficient | 0.38 |
| Wheel Size Front | 15 x 5.5 |
| Wheel Size Rear | 15 x 5.5 |
| Tire Size Front | 165/70HR-15 |
| Tire Size Rear | 165/70HR-15 |
| Caliper Front | Fixed 2-piston |
| Caliper Rear | Fixed 2-piston |
| Disc Type Front | Solid discs |
| Disc Type Rear | Solid discs |
| Disc Size Front |
11.10 in/282 mm x 0.50 in/12.7 mm
|
| Disc Size Rear |
11.22 in/285 mm x 0.39 in/10 mm
|
| 0 To 60 Mph | ~8.9 seconds |
| Top Speed |
129 mph manual/121 mph Sportomatic
|
