1996 Porsche 911 GT1 Straßenversion Technical Specifications
| Type | Concept / Prototype Car |
| Built At | Germany |
| Production | 2 |
| Engine |
All Aluminum, Water Cooled, Twin KKK Turbo Flat-6
|
| Position | Mid Longitudinal |
| Aspiration | Twin KKK Turbochargers w/Intercooler |
| Valvetrain | DOHC 4 Valves per Cyl |
| Fuel Feed | Multipoint Sequential Fuel Injection |
| Displacement | 3164 cc / 193.1 in³ |
| Bore | 95 mm / 3.74 in |
| Stroke | 74.4 mm / 2.93 in |
| Compression | 9.5:1 |
| Power | 405.7 kw / 544.0 bhp @ 7000 rpm |
| Specific Output | 171.93 bhp per litre |
| Bhp/weight | 483.56 bhp per tonne |
| Torque | 600 nm / 442.5 ft lbs @ 4250 rpm |
| Redline | 7600 |
| Body / Frame |
Carbon Fibre Body over 993 Carrera Front Chassis With Rear Tube Frame
|
| Driven Wheels | RWD w/LSD |
| Front Tires | 295/35 ZR 18 Pirelli P Zero |
| Rear Tires | 335/30 ZR 18 Pirelli P Zero |
| Front Brakes |
Internally Vented & Cross Drilled Discs w/8-Piston Calipers, ABS
|
| Rear Brakes |
Internally Vented & Cross Drilled Discs w/4-Piston Calipers, ABS
|
| Front Wheels | F 45.7 x 27.9 cm / 18 x 11 in |
| Rear Wheels | R 45.7 x 33.0 cm / 18 x 13 in |
| Steering | Rack & Pinion w/Power Assist |
| F Suspension |
Double Wishbones w/Adjustable Shock Absorbers, Anti-Roll Bar
|
| R Suspension |
Double Wishbones w/Pushrod Actuated Inboard Spring and Damper Units, Anti-Roll Bar
|
| Curb Weight | 1125 kg / 2481 lbs |
| Length | 4710 mm / 185.4 in |
| Width | 1950 mm / 76.8 in |
| Height | 1170 mm / 46.1 in |
| Transmission | Longitudinal 6-Speed Manual |
| Gear Ratios | 3.82:1, 2.15:1, 1.56:1, 1.21:1, 0.97:1, 0.75:1 |
| Final Drive | 3.444:1 |
| Top Speed | ~308.93 kph / 192 mph |
| 0 – 60 Mph | ~3.65 seconds |
| 0 – 100 Mph | ~6.3 seconds |
| 0 – 1/4 Mile | ~11.0 seconds |
