2023 Porsche 911 Carrera S (992) Technical Specifications
PDK 992 Carrera S Specs
| Model | 992 911 Carrera S |
| Engine | |
| Engine layout | Rear Engine |
| Engine type | Boxer, twin-turbo |
| Cylinders | 6 |
| Valves per cylinder | 4 |
| Construction | Aluminum crankcase and heads |
| Fuel injection | Direct Fuel Injection (DFI) |
| Fuel | Premium |
| Displacement (Liters) | 3.0 L |
| Bore/Stroke (mm/mm) | 91.0 mm / 76.4 mm |
| Maximum power output @ engine speed | 443 hp @ 6500 rpm |
| Maximum torque @ engine speed | 390 lb.-ft. @ 2300-5000 rpm |
| Maximum engine speed | 7500 |
| Compression ratio (tolerance +/- 0.3) | 10.2:1 |
| Output per liter | 148 hp |
| Lubrication | Integrated dry-sump |
| Power to weight ratio (lb/hp) | 7.7 |
| Drivetrain | Rear-wheel drive |
| Chassis & Suspension | |
| Body | Monocoque lightweight body in a combination of steel, aluminum, and magnesium |
| Front Axle | MacPherson strut with anti-roll bar |
| Rear Axle | Aluminum multi-link with anti- roll bar |
| Steering System | Variable ratio electromec. power steering |
| Steering Ratio | 15.0 : 1 (on-center) to 12.25 : 1 |
| Steering Ratio with rear-axle steering | 14.1 : 1 (on-center) to 12.25 : 1 |
| Turning Circle | 36.8 ft / 35.8 ft. (with rear axle steering) |
| Brakes & Wheels | |
| Caliper type | Aluminum monobloc fixed- caliper brake |
| Rotor material | Steel |
| Caliper color | Red |
| Number of pistons (front/rear) | 6 / 4 |
| Rotor diameter (front/rear) mm | 350 mm / 350 mm |
| Rotor thickness (front/rear) mm | 34 mm / 28 mm |
| Caliper type (optional PCCB system) | Aluminum monobloc fixed- caliper brake |
| Rotor material (optional PCCB system) | Carbon-ceramic composite |
| Caliper color (optional PCCB system) | Yellow |
| Number of pistons (front/rear – optional PCCB system) | 6 / 4 |
| Rotor diameter (front/rear – optional PCCB system) mm | 410 mm / 390 mm |
| Rotor thickness (front/rear – optional PCCB system) mm | 36 mm / 32 mm |
| Standard wheels | 20″ / 21″ Carrera S |
| Wheels (front/rear) | 8.5J x 20″ / 11.5j X 21″ |
| Tires (front/rear) | 245/35 ZR 20 / 305/30 ZR 21 |
| Transmission | |
| Number of gears | 8 |
| Transmission type | 8-speed dual-clutch PDK |
| Ratios | |
| 1st | 4.89 |
| 2nd | 3.17 |
| 3rd | 2.15 |
| 4th | 1.56 |
| 5th | 1.18 |
| 6th | 0.94 |
| 7th | 0.76 |
| 8th | 0.61 |
| Reverse | 3.99 |
| Final drive ratio front axle | 0 |
| Dimensions, Aerodynamics, & Weight | |
| Length with standard PASM Sport Suspension (inches/mm) | 177.9 in. / 4519 mm |
| Length with optional PASM Sport Suspension (inches/mm) | 178.4 in. / 4530 mm |
| Wheelbase (inches/mm) | 96.5 in. / 2450 mm |
| Width w/ mirrors (inches/mm) | 79.7 in. / 2024 mm |
| Width w/o mirrors (inches/mm) | 72.9 in. / 1852 mm |
| Height with standard PASM suspension (inches/mm) | 51.2 in. / 1300 mm |
| Height with optional PASM Sport Suspension (inches/mm) | 50.8 in. / 1291 mm |
| Track width front (inches/mm) | 62.5 in. / 1589 mm |
| Track width rear (inches/mm) | 61.2 in. / 1557 mm |
| Drag coefficient (Cd) | 0.31 |
| Cargo area volume (cu.-ft.) front trunk | 132 I / 4.66 cu.-ft. |
| Cargo area volume (cu.-ft.) rear seats | 264 / 9.32 cu.-ft. |
| Fuel tank capacity – refill volume (gal) | 16.9 gal. |
| Curb weight (lbs) | 3382 lbs. |
| Gross Vehicle Weight (lbs) | 4376 lbs. |
| Payload range (lbs) | 994 lbs. |
| Performance | |
| Top track speed PDK (mph) | 191 mph |
| Acceleration 0-60 PDK (sec) | 3.5 sec. |
| Acceleration 0-60 PDK with Launch Control (sec) | 3.3 sec. |
| Quarter mile time PDK (sec) | 11.9 sec. |
| Quarter mile time PDK with Launch Control (sec) | 11.7 sec. |
| Fuel Economy/Rating | |
| Rating | – |
| City | 18 mpg |
| Highway | 24 mpg |
| Combined | 20 mpg |
Manual 992 Carrera S Specs
| Model | 992 911 Carrera S with Manual |
| Engine | |
| Engine layout | Rear Engine |
| Engine type | Boxer, twin-turbo |
| Cylinders | 6 |
| Valves per cylinder | 4 |
| Construction | Aluminum crankcase and heads |
| Fuel injection | Direct Fuel Injection (DFI) |
| Fuel | Premium |
| Displacement (Liters) | 3.0 L |
| Bore/Stroke (mm/mm) | 91.0 mm / 76.4 mm |
| Maximum power output @ engine speed | 443 hp @ 6500 rpm |
| Maximum torque @ engine speed | 390 lb.-ft. @ 2300-5000 rpm |
| Maximum engine speed | 7500 |
| Compression ratio (tolerance +/- 0.3) | 10.2:1 |
| Output per liter | 148 hp |
| Lubrication | Integrated dry-sump |
| Power to weight ratio (lb/hp) | 7.5 |
| Drivetrain | Rear-wheel drive |
| Chassis & Suspension | |
| Body | Monocoque lightweight body in a combination of steel, aluminum, and magnesium |
| Front Axle | MacPherson strut with anti-roll bar |
| Rear Axle | Aluminum multi-link with anti- roll bar |
| Steering System | Variable ratio electromec. power steering |
| Steering Ratio | 15.0 : 1 (on-center) to 12.25 : 1 |
| Steering Ratio with rear-axle steering | 14.1 : 1 (on-center) to 12.25 : 1 |
| Turning Circle | 36.8 ft / 35.8 ft. (with rear axle steering) |
| Brakes & Wheels | |
| Caliper type | Aluminum monobloc fixed- caliper brake |
| Rotor material | Steel |
| Caliper color | Red |
| Number of pistons (front/rear) | 6 / 4 |
| Rotor diameter (front/rear) mm | 350 mm / 350 mm |
| Rotor thickness (front/rear) mm | 34 mm / 28 mm |
| Caliper type (optional PCCB system) | Aluminum monobloc fixed- caliper brake |
| Rotor material (optional PCCB system) | Carbon-ceramic composite |
| Caliper color (optional PCCB system) | Yellow |
| Number of pistons (front/rear – optional PCCB system) | 6 / 4 |
| Rotor diameter (front/rear – optional PCCB system) mm | 410 mm / 390 mm |
| Rotor thickness (front/rear – optional PCCB system) mm | 36 mm / 32 mm |
| Standard wheels | 20″ / 21″ Carrera S |
| Wheels (front/rear) | 8.5J x 20″ / 11.5j X 21″ |
| Tires (front/rear) | 245/35 ZR 20 / 305/30 ZR 21 |
| Transmission | |
| Number of gears | 7 |
| Transmission type | 7-speed manual transmission |
| Ratios | |
| 1st | 3.91 |
| 2nd | 2.29 |
| 3rd | 1.58 |
| 4th | 1.18 |
| 5th | 0.94 |
| 6th | 0.79 |
| 7th | 0.62 |
| 8th | |
| Reverse | 3.55 |
| Final drive ratio front axle | 0 |
| Dimensions, Aerodynamics, & Weight | |
| Length with standard PASM Sport Suspension (inches/mm) | 177.9 in. / 4519 mm |
| Length with optional PASM Sport Suspension (inches/mm) | 178.4 in. / 4530 mm |
| Wheelbase (inches/mm) | 96.5 in. / 2450 mm |
| Width w/ mirrors (inches/mm) | 79.7 in. / 2024 mm |
| Width w/o mirrors (inches/mm) | 72.9 in. / 1852 mm |
| Height with standard PASM suspension (inches/mm) | 51.2 in. / 1300 mm |
| Height with optional PASM Sport Suspension (inches/mm) | 50.8 in. / 1291 mm |
| Track width front (inches/mm) | 62.5 in. / 1589 mm |
| Track width rear (inches/mm) | 61.2 in. / 1557 mm |
| Drag coefficient (Cd) | 0.31 |
| Cargo area volume (cu.-ft.) front trunk | 132 I / 4.66 cu.-ft. |
| Cargo area volume (cu.-ft.) rear seats | 264 I / 9.32 cu.-ft. |
| Fuel tank capacity – refill volume (gal) | 16.9 gal. |
| Curb weight (lbs) | 3298 lbs. |
| Gross Vehicle Weight (lbs) | 4431 lbs. |
| Payload range (lbs) | 945 lbs. |
| Performance | |
| Top track speed PDK (mph) | 191 mph |
| Acceleration 0-60 PDK (sec) | 4.0 sec. |
|
Acceleration 0-60 PDK with Launch Control (sec)
|
|
| Quarter mile time PDK (sec) | |
|
Quarter mile time PDK with Launch Control (sec)
|
|
| Fuel Economy/Rating | |
| Rating | Premium |
| City | 17 mpg |
| Highway | 25 mpg |
| Combined | 20 mpg |
