2023 Porsche 911 Carrera 4S Cabriolet (992) Technical Specifications
PDK 992 Carrera 4S Cabriolet Specs
| Model | 992 911 Carrera 4S Cabriolet |
| Engine | |
| Engine layout | Rear Engine |
| Engine type | Boxer, twin-turbo |
| Cylinders | 6 |
| Valves per cylinder | 4 |
| Construction | Aluminum crankcase and heads |
| Fuel injection | Direct Fuel Injection (DFI) |
| Fuel | Premium |
| Displacement (Liters) | 3.0 L |
| Bore/Stroke (mm/mm) | 91.0 mm / 76.4 mm |
| Maximum power output @ engine speed | 443 bhp @ 6500 rpm |
| Maximum torque @ engine speed | 390 ft lbs @ 2300-5000 rpm |
| Maximum engine speed | 7500 |
| Compression ratio (tolerance +/- 0.3) | 10.2 1 |
| Output per liter | 148 hp |
| Lubrication | Integrated dry-sump |
| Power to weight ratio (lb/hp) | 8.2 |
| Drivetrain | Active all-wheel drive |
| Chassis & Suspension | |
| Body |
Monocoque lightweight body in a combination of steel, aluminum, and magnesium
|
| Front Axle | MacPherson strut with anti- roll bar |
| Rear Axle | Aluminum multi-link with anti-roll bar |
| Steering System | Variable ratio electromec. power steering |
| Steering Ratio | 15.0:1 (on-center) to 12.25:1 |
| Steering Ratio with rear-axle steering | 14.1:1 (on-center) to 12.25:1 |
| Turning Circle | 36.8 ft / 35.8 ft. (with rear axle steering) |
| Brakes & Wheels | |
| Caliper type | Aluminum monobloc fixed- caliper brake |
| Rotor material | Steel |
| Caliper color | Red |
| Number of pistons (front/rear) | 6 / 4 |
| Rotor diameter (front/rear) mm | 350 mm / 350 mm |
| Rotor thickness (front/rear) mm | 34 mm / 28 mm |
| Caliper type (optional PCCB system) | Aluminum monobloc fixed- caliper brake |
| Rotor material (optional PCCB system) | Carbon-ceramic composite |
| Caliper color (optional PCCB system) | Yellow |
| Number of pistons (front/rear – optional PCCB system) | 6 / 4 |
| Rotor diameter (front/rear – optional PCCB system) mm | 410 mm / 390 mm |
| Rotor thickness (front/rear – – optional PCCB system) mm | 36 mm / 32 mm |
| Standard wheels | 20″ / 21″ Carrera S |
| Wheels (front/rear) | 8.5J X 20″ / 11.5j X 21″ |
| Tires (front/rear) | 245/35 ZR 20 / 305/30 ZR 21 |
| Transmission | |
| Number of gears | 8 |
| Transmission type | 8-speed dual-clutch PDK |
| Ratios | |
| 1st | 4.89 |
| 2nd | 3.17 |
| 3rd | 2.15 |
| 4th | 1.56 |
| 5th | 1.18 |
| 6th | 0.94 |
| 7th | 0.76 |
| 8th | 0.61 |
| Reverse | 3.99 |
| Final drive ratio front axle | 3.33 |
| Rear Axle Ratio / rear constant transaxle ratio | 3.39 / 0.92 |
| Clutch 1/Clutch 2 diameter (inches) | 8.7 / 6.6 inches (PDK) |
| Dimensions, Aerodynamics, & Weight | |
| Length with standard PASM Sport Suspension (inches/mm) | 177.9 in. / 4519 mm |
| Length with optional PASM Sport Suspension (inches/mm) | 178.4 in / 4530 mm |
| Wheelbase (inches/mm) | 96.5 in. / 2450 mm |
| Width w/ mirrors (inches/mm) | 79.7 in. / 2024 mm |
| Width w/o mirrors (inches/mm) | 72.9 in. / 1852 mm |
| Height with standard PASM suspension (inches/mm) | 51.2 in. / 1299 mm |
| Height with optional PASM Sport Suspension (inches/mm) | 50.8 in. / 1289 mm |
| Track width front (inches/mm) | 62.5 in. / 1589 mm |
| Track width rear (inches/mm) | 61.2 in. / 1557 mm |
| Cargo area volume (cu.-ft.) front trunk | 132 L/ 4.66 cu.-ft. |
| Cargo area volume (cu.-ft.) rear seats | 163 L / 5.75 cu.-ft. |
| Fuel tank capacity – refill volume (gal) | 17.6 gal. |
| Curb weight (lbs) | 3641 lbs. |
| Gross Vehicle Weight (lbs) | 4553 lbs. |
| Payload range (lbs) | 912 lbs. |
| Performance | |
| Top track speed PDK (mph) | 188 mph |
| Acceleration 0-60 PDK (sec) | 3.6 sec. |
| Acceleration 0-60 PDK with Launch Control (sec) | 3.4 sec. |
| Quarter mile time PDK (sec) | 12.0 sec. |
| Quarter mile time PDK with Launch Control (sec) | 11.8 sec. |
| Fuel Economy/Rating | |
| City | 18 mpg |
| Highway | 23 mpg |
| Combined | 20 mpg |
Manual 992 Carrera 4S Cabriolet Specs
| Model |
992 911 Carrera 4S Cabriolet with Manual
|
| Engine | |
| Engine layout | Rear Engine |
| Engine type | Boxer, twin-turbo |
| Cylinders | 6 |
| Valves per cylinder | 4 |
| Construction | Aluminum crankcase and heads |
| Fuel injection | Direct Fuel Injection (DFI) |
| Fuel | Premium |
| Displacement (Liters) | 3.0 L |
| Bore/Stroke (mm/mm) | 91.0 mm / 76.4 mm |
| Maximum power output @ engine speed | 443 bhp @ 6500 rpm |
| Maximum torque @ engine speed | 390 ft lbs @ 2300-5000 rpm |
| Maximum engine speed | 7500 |
| Compression ratio (tolerance +/- 0.3) | 10.2 1 |
| Output per liter | 148 hp |
| Lubrication | Integrated dry-sump |
| Power to weight ratio (lb/hp) | 8.1 |
| Drivetrain | Active all-wheel drive |
| Chassis & Suspension | |
| Body |
Monocoque lightweight body in a combination of steel, aluminum, and magnesium
|
| Front Axle | MacPherson strut with anti- roll bar |
| Rear Axle | Aluminum multi-link with anti- roll bar |
| Steering System | Variable ratio electromec. power steering |
| Steering Ratio | 15.0:1 (on-center) to 12.25:1 |
| Steering Ratio with rear-axle steering | 14.1:1 (on-center) to 12.25:1 |
| Turning Circle | 36.8 ft / 35.8 ft. (with rear axle steering) |
| Brakes & Wheels | |
| Caliper type | Aluminum monobloc fixed- caliper brake |
| Rotor material | Steel |
| Caliper color | Red |
| Number of pistons (front/rear) | 6 / 4 |
| Rotor diameter (front/rear) mm | 350 mm / 350 mm |
| Rotor thickness (front/rear) mm | 34 mm / 28 mm |
| Caliper type (optional PCCB system) | Aluminum monobloc fixed- caliper brake |
| Rotor material (optional PCCB system) | Carbon-ceramic composite |
| Caliper color (optional PCCB system) | Yellow |
| Number of pistons (front/rear – optional PCCB system) | 6 / 4 |
| Rotor diameter (front/rear – optional PCCB system) mm | 410 mm / 390 mm |
| Rotor thickness (front/rear – optional PCCB system) mm | 36 mm / 32 mm |
| Standard wheels | 20″ / 21″ Carrera S |
| Wheels (front/rear) | 8.5J X 20″ / 11.5j X 21″ |
| Tires (front/rear) | 245/35 ZR 20 / 305/30 ZR 21 |
| Transmission | |
| Number of gears | 7 |
| Transmission type | 7-speed manual |
| Ratios | |
| 1st | 3.91 |
| 2nd | 2.29 |
| 3rd | 1.58 |
| 4th | 1.18 |
| 5th | 0.94 |
| 6th | 0.79 |
| 7th | 0.62 |
| Reverse | 3.55 |
| Final drive ratio front axle | 3.33 |
| Rear Axle Ratio | 3.56 |
| Clutch diameter (inches) | 9.0 inches |
| Dimensions, Aerodynamics, & Weight | |
| Length with standard PASM Sport Suspension (inches/mm) | 177.9 in. / 4519 mm |
| Length with optional PASM Sport Suspension (inches/mm) | 178.4 in / 4530 mm |
| Wheelbase (inches/mm) | 96.5 in. / 2450 mm |
| Width w/ mirrors (inches/mm) | 79.7 in. / 2024 mm |
| Width w/o mirrors (inches/mm) | 72.9 in. / 1852 mm |
| Height with standard PASM suspension (inches/mm) | 51.2 in. / 1299 mm |
| Track width front (inches/mm) | 62.5 in. / 1589 mm |
| Track width rear (inches/mm) | 61.2 in. / 1557 mm |
| Cargo area volume (cu.-ft.) front trunk | 132 L/ 4.66 cu.-ft. |
| Cargo area volume (cu.-ft.) rear seats | 163 L / 5.75 cu.-ft. |
| Fuel tank capacity – refill volume (gal) | 17.6 gal. |
| Curb weight (lbs) | 3556 lbs. |
| Gross Vehicle Weight (lbs) | 4553 lbs. |
| Payload range (lbs) | 912 lbs. |
| Performance | |
| Top track speed (mph) | 188 mph |
| Acceleration 0-60 mph (sec) | 4.2 sec. |
| Fuel Economy/Rating | |
| City | 17 mpg |
| Highway | 24 mpg |
| Combined | 20 mpg |
