| Engine layout |
Rear Engine |
| Engine type |
Boxer, twin-turbo |
| Cylinders |
6 |
| Valves per cylinder |
4 |
| Construction |
Aluminum crankcase and heads |
| Fuel injection |
Direct Fuel Injection (DFI) |
| Fuel |
Premium |
| Displacement (Liters) |
3.0 L |
| Bore/Stroke (mm/mm) |
91.0 mm / 76.4 mm |
| Max power output |
379 hp @ 6500 rpm |
| Maximum torque |
331 lb.-ft @ 1950-5000 rpm |
| Compression ratio (tolerance +/- 0.3) |
10.2:1 |
| Output per liter |
126.3 hp/l |
| Lubrication |
Integrated dry-sump |
| Power to weight ratio (lb/hp) |
9.6 lb/hp |
| Drivetrain |
Rear-engine |
| Rear Axle |
|
| Steering System |
|
| Steering Ratio |
Variable |
| Turning Circle |
36.8 ft |
| Brakes & Wheels |
|
| Caliper type |
Aluminum monobloc fixed-caliper brake |
| Rotor material |
Cast-iron |
| Caliper color |
Black |
| Number of pistons (front/rear) |
4/4 |
| Rotor diameter (front/rear) mm |
330 mm / 330 mm |
| Rotor thickness (front/rear) mm |
34 mm/28 mm |
| Caliper type (optional PCCB system) |
Aluminum monobloc fixed-caliper brake |
| Rotor material (optional PCCB system) |
Ceramic |
| Caliper color (optional PCCB system) |
Yellow |
| Number of pistons (front/rear – optional PCCB system) |
6/4 |
| Rotor diameter (front/rear – optional PCCB system) mm |
410mm / 390mm |
| Rotor thickness (front/rear – optional PCCB system) mm |
36 mm / 32 mm |
| Standard wheels |
19 / 20-inch |
| Wheels (front/rear) |
8.5 X 19 / 11.5X 20 |
| Tires (front/rear) |
235/40 R 19 / 295/35R 20 |
| Transmission |
|
| Number of gears |
8 |
| Transmission type |
Automatic |
| Ratios |
|
| 1st |
4.89 |
| 2nd |
3.17 |
| 3rd |
2.15 |
| 4th |
1.56 |
| 5th |
1.18 |
| 6th |
0.94 |
| 7th |
0.76 |
| 8th |
0.61 |
| Reverse |
3.99 |
| Final drive ratio front axle |
3.33 |
| Rear Axle Ratio / rear constant transaxle ratio |
3.385 / 0.923 |
| Clutch 1/Clutch 2 diameter (inches) |
8.7 inches / 6.6 inches |
| Length with standard PASM Sport Suspension (inches/mm) |
177.9 in |
| Wheelbase (inches/mm) |
96.5 in |
| Width w/ mirrors (inches/mm) |
79.7 in |
| Width w/o mirrors (inches/mm) |
72.9 in |
| Height with standard PASM suspension (inches/mm) |
51.1 in |
| Track width front (inches/mm) |
62.7 in |
| Track width rear (inches/mm) |
61.2 in |
| Cargo area volume (cu.-ft.) front trunk |
cu.-ft. |
| Cargo area volume (cu.-ft.) rear seats |
5.75 cu.-ft |
| Fuel tank capacity – refill volume (gal) |
gal |
| Curb weight (lbs) |
3614 |
| Gross Vehicle Weight (lbs) |
4497 |
| Payload range (lbs) |
883 |
| Performance |
|
| Top track speed (mph) |
179 |
| Acceleration 0-60 (sec) |
4.2s |
| Acceleration 0-60 with Sport Chrono Package (sec) |
4.0s |
| Quarter mile time (sec) |
12.5s |
| Quarter mile time with Launch Control (sec) |
12.7s |
| Fuel Economy/Rating |
|
| City |
18 |
| Highway |
24 |
| Combined |
20 |
