1976 – 1977 Porsche 911 Carrera 3.0 Technical Specifications
| Type | 2+2 FHC |
| Number of doors | 2 |
| Engine | 3.0 L Aircooled Flat 6 |
| Engine Position | Rear |
| Engine Layout | Longitudinal |
| Drive Wheels | Rear wheel drive |
| Layout | Flat 6 |
| Type |
Dry sumped, SOHC, 2 valves per cylinder
|
| Main bearings | 8 |
| Bore x stroke | 95.00 mm. × 70.40 mm. |
| Bore / stroke ratio | 1.34 |
| Displacement | 2994 cc / 182.70 cu in |
| Compression | 8.5 |
| Fuel System | Bosch K-Jetronic fuel injection |
| Aspiration | Normal |
| Catalytic Converter | Normal |
| Max. output | 197 bhp @ 6000 rpm |
| Max. torque | 188 ft lbs @ 4200 rpm |
| Coolant | Air |
| Wheelbase | 2268 mm / 89.29 in |
| Track front | 1372 mm / 54.01 in |
| Track rear | 1397 mm / 55.00 in |
| Length | 4290 mm / 168.89 in |
| Width | 1665 mm / 65.55 in |
| Ground clearance | 121 mm / 4.76 in |
| Kerb weight | 1120 kg / 2469.17 lb |
| Fuel capacity | 79.6 l / 21.02 US gal |
| Torque Split | N/A |
| Steering | rack & pinion |
| Front Suspension | I.W.TB. |
| Rear Suspension | I.STA.TB. |
| Tyres Front | 185/70 VR 15 |
| Tyres Rear | 215/60 VR 15 |
| Brakes F/r | Di/Di |
| Braked Area | 3245 cm2 |
| Gearbox | 5 speed manual |
| Top Gear Ratio | 0.82 |
| Final Drive Ratio | 3.88 |
| 0 – 60 mph | 6.5 seconds |
| Top Speed | 143 mph |
